WeatherLink for Vantage Pro2 Sprinkler & Irrigation Control Module.
Use your Vantage Pro2 to turn your irrigation system on or off based on current weather conditions no more watering the lawn when it's raining!

Installation is quick and easy. Connects to most common irrigation systems including Rain Bird, Rain Master, and Toro. For the industrial controllers used in agricultural and turf management, provides electronic pulses for wind, rain, and evapotranspiration.

For homeowners, use the alarm settings in the Vantage Pro2 console. Set the alarms to water your garden before a hard freeze hits, or to turn the system off if it starts raining. Add our optional solar radiation sensor, and you can even set the alarms to turn the system on or off based on evapotranspiration. Datalogger also simultaneously logs and stores the data, which can later be downloaded to your PC for all the graphing, charting, and analysis inlcuded with our standard WeatherLink. To track multiple stations on the same computer, add one WeatherLink for each station. To view the same on multiple computers, add one Extra User License for each computer.

Includes streaming data logger, software on CD, and an 8ft (2.4m) cable to connect the data logger to your computer or modem. For downloading to a PC, you need Windows 95/NT4.0/98/2000/ME/XP and one free serial port. Compatible with both original Vantage Pro and Vantage Pro2. Not for use with WeatherLink for Mac... sorry. FREE Shipping USA & Int'l via USPS or UPS - usually 3-7 days in USA; 4-10 days Int'l

Function Specification
Operating Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . -40° to 140°F (-40° to 60°C)
Output Contact Closures . . . . . . . . . . . . . . . . . . . . . . . . . 4: Wind, Rain, ET & Alarm Contact Specifications, Terminal Block with stainless steel cage clamp screw terminals.
Each of the four output contacts is rated as follows:
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Photo-coupled MOS FET
Load Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28VAC or 48VDC
Peak Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 60 V, maximum
Load Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 1.8 A, continuous Maximum at 77°F (25°C), derated to 0.7 A at 185°F, (85°C)
Peak Load Current. . . . . . . . . . . . . . . . . . . . . . . . . . 6 A for 100 msec., maximum
ON Resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 Ohms, maximum
OFF Leakage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 uA, maximum
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . 550 mW, maximum
Output Contact Closure Functions:
Wind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pulse per 1 mph in 2 seconds. Frequency in Hz is half the wind speed in mph
Rain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pulse per tip of the rain bucket. Depends upon rain collector type setting in console (0.01" or 0.2 mm)
ET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pulse per 0.01" in Industrial mode only; acts as an alarm in Residential mode (see below) only
Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Triggers on any active alarm set on the Vantage Pro or Pro2 console/ Envoy. Functions according to settings listed below:
Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 255 minutes (user selectable). Determines how long the alarm output should stay active once it is triggered. Default = 10 minutes
Reactivation . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 255 minutes (user selectable). Determines how long to leave the alarm output deactivated once it is deactivated. Default = 0.
Pulse Width . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 9999 milliseconds (user selectable). Default = 2000 milliseconds (2 seconds).
Activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . Continuous or Pulse (1-time) (user selectable). Determines whether a pulse for alarm activation is continuous throughout the activation time or a one time pulse. Pulsed relay oriented devices will require the onetime pulse. Default = Continuous
Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Normally Open or Normally Closed (user-selectable). Determines whether the circuit stays open or closed when no alarms are active. The opposite behavior occurs for an active alarm condition. Normally Closed is the most typical operation for Irrigation controller use. Default = Normally Closed.
Test Mode Function . . . . . . . . . . . . . . . . . . . . Available. Continuous, Open, or Closed circuit (user-selectable).
Residential Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Used with a Residential Irrigation System Controller to inhibit the watering cycle. This type of sprinkler controller will be what is typically installed by most homeowners and will have inputs for a Common and in many cases a Rain Sensor. The following functions are available for this mode only:
Irrigation Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 to 255 hours (user-selectable). Indicates the number of hours between entire watering cycles, which are the period of time it takes for all programmed cycles on the Irrigation controller to start, finish and then begin again. Default = 24 (daily watering cycle).
Rain - ET Threshold. . . . . . . . . . . . . . . . . . . . . . . . . -9.99" to +9.99", (253.7 mm) (user-selectable) Difference between the Total Rainfall minus the Total Evapotranspiration (ET) over the Irrigation Cycle (see above). Update Interval = 1 hour. Default = 0.
Rain Rate Cut-Off . . . . . . . . . . . . . . . . . . . . . . . . . . 0.00" to 0.99"/hour (25.1 mm/hour) or off (user-selectable). Used to inhibit the irrigation cycle during heavy rain situations. Default = 0.30"/ hour (7.6 mm/hour). This function can be disabled in the streaming data utility bundled with WeatherLink 5.6 or later.
Data Logger Functions
Control Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Set archive interval, set/clear calibration numbers, set Longitude/ Latitude, set Year-to-Date rain total, set/clear alarm thresholds, clear total values, set time/date.
Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Data may be transferred automatically to your computer once an hour using the Auto Download command. More frequent downloads can be selected to support Internet file transfers. Only new archive data is transferred during the download.

Data Logger Archived Data
The Data Logger stores up to 2560 archive records (one 52-byte record per archive interval) for later transfer to your computer. The archive records are stored in 128K of non-volatile memory; protecting the data even if the console loses power. Maxima, minima, averages, and totals are taken over the archive interval.
Archive Record Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . Time/Date of Record, Inside Temperature (last or avg.), Outside
Temperature (last or avg.), Maximum Air Temperature, Minimum Air Temperature, Wind Direction (dominant), Wind Speed (average), Maximum Wind Speed, Rainfall (total), Rain Rate, Inside Humidity (last), Outside Humidity (last), Barometric Pressure (last), Solar Radiation, Hi Solar Radiation, UV, Hi UV, Evapotranspiration, Forecast, Leaf Temperature (2), Leaf Wetness (2), Extra Humidity (2), Extra Temperature (2), Soil Temperature (4), Soil Moisture (4), Wind Samples, Wind Tx, Length of Archive Interval, ISS ReceptionArchive Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . User-selectable from the following intervals (in minutes): 1, 5, 10, 15, 30, 60, or 120
Archive Storage Capacity (the amount of time before the archive is completely filled):

• 1 Minute Archive Interval . . . . . . . . . . . . . . . . . . . . . 42 hours

• 5 Minute Archive Interval . . . . . . . . . . . . . . . . . . . . . 8 days

• 10 Minute Archive Interval . . . . . . . . . . . . . . . . . . . . 17 days

• 15 Minute Archive Interval . . . . . . . . . . . . . . . . . . . . 26 days

• 30 Minute Archive Interval . . . . . . . . . . . . . . . . . . . . 53 days

• 60 Minute Archive Interval . . . . . . . . . . . . . . . . . . . . 106 days

• 120 Minute Archive Interval . . . . . . . . . . . . . . . . . . . 213 days
  Download . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Data may be transferred automatically from the data logger to your computer up to once an hour using the Auto Download command. Data can be transferred more frequently, from once a minute to once every two hours, to support Internet uploading and other data sharing features. Only new archive data is transferred during the download.

  Data Display Options
  Some of the weather data and reports listed below require optional sensors.
  Real-Time Displays (these displays update in real-time):
  Graphical Bulletin . . . . . . . . . . . . . . . . . . . . . . . . . . Inside Temperature, Outside Temperature, Wind Direction (0°- 360°), Wind Speed, Daily Rain Total, Monthly Rain Total, Year-to-Date Rain Total, Storm Total, Rain Rate, Inside Humidity, Outside Humidity, Barometer, Barometer 6-hour Plot, Evapotranspiration (ET) (day, month, year), Today’s Highs and Lows, Forecast Icons, Forecast Text, and Illuminated Fraction of the Moon Disk.
  Text-Based Summary . . . . . . . . . . . . . . . . . . . . . . . Inside Temperature, Outside Temperature, Wind Direction (0°- 360°), Wind Speed, Daily Rain Total, Monthly Rain Total, Year-to-Date Rain Total, Storm Total, Rain Rate, Inside Humidity, Outside Humidity, Barometer, UV, Solar Radiation, ET (day, month, year), Today’s Highs and Lows, Forecast Text, and Moon Phase.
  Update Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . Two seconds (approximately)
  Plotting Displays:
  Plot Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Enables graphing of all database information (multiple variables may be plotted on a single graph) over any of the following spans (1 hr, 4 hr, 8 hr, 12 hr, 1 day, 3 days, Week, Month, Year). Multiple dates may also be plotted on the same graph.
  Strip Charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Four stacked line graphs (multiple variables may be plotted on a single graph), which update at the time of each archive interval. Strip charts may use any of the following spans (1 hr, 4 hr, 8 hr, 12 hr, 1 day, 3 days, Week, Month, Year).
  Reports:
  NOAA Monthly Summary . . . . . . . . . . . . . . . . . . . . . Based on the National Oceanic and Atmospheric Administration (NOAA) Monthly Weather Watcher report
  NOAA Yearly Summary . . . . . . . . . . . . . . . . . . . . . . Based on the National Oceanic and Atmospheric Administration (NOAA) Yearly Weather Watcher report
  Yearly Rainfall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Calculates rainfall totals broken down by month and year. Rainfall data may be altered and data may be added to reflect rainfall totals for months and years which are not contained in your weather database.
  Degree-Days . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tracks degree-days and progress towards development for an unlimited number of crops or pests; base and upper development thresholds and development totals entered by user.
  Temperature/Humidity Hours . . . . . . . . . . . . . . . . . . Calculates the number of hours the temperature has been either above or below a given threshold, and that during which time the humidity was above a given threshold from a given start date. Typically used to track conditions for the development of agricultural pests and molds.
  Soil Temperature Hours . . . . . . . . . . . . . . . . . . . . . . Calculates the time that soil temperature has been above freezing (or some other threshold). Typically used to determine a time to plant crops.
  Chilling Requirements . . . . . . . . . . . . . . . . . . . . . . . Calculates the number of hours spent below a specified temperature during a specified period of time. Typically used to determine if the coldness requirement for a fruit tree in dormancy has been met.
  Bright Sunshine Hours . . . . . . . . . . . . . . . . . . . . . . . Calculates amount of sunshine for a selected time period.
  Leaf Wetness Hours . . . . . . . . . . . . . . . . . . . . . . . . Calculates the amount of leaf wetness hours over a selected time period.
  Fuel Demand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Estimates fuel usage based on past usage and outside temperatures.
  Total ET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Calculates ET for a selected time period.
  Sunrise & Sunset Times. . . . . . . . . . . . . . . . . . . . . . Calculates sunrise and sunset times for any given latitude, longitude and date.
